MANKIND Planet 20"

€495.00
Tax included

The Planet 20” Bike is our entry level, beginner bike for the younger and smaller rider. Therefore we have designed size, geometry and weight in order to make it as ideal as possible to learn to ride BMX and to have a great time. The Planet is available in 14” ,16” and 20”. The Planet 20” has a shorter 20.0” Top Tube, and lower 8.25” bar for an easy and direct handling for the younger rider from about 150cm to 170cm of size.


3 Items

FRAME: 1020 Hi-Ten Steel Frame - Top & Down Tube Gusset

TOP TUBE: 20.0”

CHAIN STAY: 13.25”

HEAD TUBE: 75°

SEAT TUBE: 71°

BB HEIGHT: 11.5”

STAND OVER: 8.3”

BRAKE MOUNTS Welded

FORK: 1020 Hi-Ten Steel - 2-PC Steerer, Tapered Legs, 28mm offset

BARS: BARS 1020 Hi-Ten Steel, 8.25” Rise, Back: 12°/ Up: 2°, Width: 28.3”

GRIPS: Mankind Asadi Grips

BAR ENDS: Mankind Nylon

STEM: Mankind Control Top Load Stem - Alloy - 50mm reach

HEADSET: Standard 1-1/8” Threadless

BRAKE: Alloy U-brake

BRAKE LEVER: Alloy Lever - 2-Finger Design

REAR HUB: Mankind Control Cassette Hub – Semi Sealed - 14mm axle - 9t

FRONT HUB: Steel - Loose Ball - 3/8” axle

SPROCKET: Mankind Control Steel 25t

CRANKS: Chromoly – 8 Spline - 3-Piece - 170mm - 19mm

BOTTOM BRACKET: American Loose Ball - 19mm

CHAIN: PYC 410 - black

PEDALS: Plastic Platform 9/16”

FRONT RIM: 6061 Alloy - Single Wall 36H

REAR RIM: 6061 Alloy - Single Wall 36H

SPOKES: Steel Spokes – 14mm nipples - black

FRONT TIRE: Park/Street Tire LP 60 PSI - 2.3”

REAR TIRE: Park/Street Tire LP 60 PSI - 2.3”

PEG:  None

SEAT: Mankind Planet Mid Seat/Post Combo

SEAT POST: Seat/Post Combo

SEAT POST CLAMP: Mankind Alloy - black

COLORS: Ed Black, Semi Matte Blue

WEIGHT: 10,60 kg

3 Items

Specific References

upc
663140948160
