TREK Marlin 7 Gen 3

Chassis Size: XXS, XS

Alpha Silver Aluminum, curved top tube, internal cable routing for rear derailleur and dropper post, rack and kickstand mounts, ThruSkew 135x5mm

Size: S, M, ML, L, XL, XXL

Alpha Silver Aluminum, internal cable routing for rear derailleur and dropper post, rack and kickstand mounts, 135x5mm ThruSkew

*Fork Size: XXS

RockShox Judy Silver, Solo Air spring, rebound adjust, TurnKey hydraulic lockout, 42mm offset for 27.5" wheels, 100mm QR, 80mm travel

Size: XS, S

RockShox Judy Silver, Solo Air spring, rebound adjust, TurnKey hydraulic lockout, 42mm offset for 27.5" wheels, 100mm QR, 100mm travel

Size: M, ML, L, XL, XXL

RockShox Judy Silver, Solo Air spring, rebound adjust, TurnKey hydraulic lockout, 46mm offset for 29" wheels, 100mm QR, 100mm travel

Max. compatible fork travel 120mm, XXS: 80mm

Wheels

Front hub Formula DC-20 LW, alloy, 6-bolt, 5x100mm QR

Rear hub Formula DC-22LW, 6 bolt, Shimano 8/9/10 freewheel, QR 135x5mm

Rear lock QR 173x5mm

Circle Bontrager Kovee, double chamber, Tubeless Ready, 28 hole, 23mm width, Presta valve

*Tire Size: XXS

Maxxis Ardent, tubeless ready, EXO casing, folding bead, 60tpi, 26x2.4"

Size: XS , S

Maxxis Ardent, tubeless ready, EXO casing, folding bead, 60tpi, 27.5x2.4"

Size: M , ML , L , XL , XXL

Maxxis Ardent, tubeless ready, EXO casing, folding bead, 60tpi, 29x2.4"

Max. tire size Frame: 29x2.40" (XXS: 26x2.40", XS & S: 27.5x2.40"), Fork: See manufacturer

Transmission

Command SRAM SX Eagle, 12 speed

Rear derailleur SRAM SX Eagle

*Cushion Size: XXS

SRAM SX Eagle, 30T steel chainring, 49mm chainline, 155mm length

Size: XS, S, M

SRAM SX Eagle, 30T steel chainring, 49mm chainline, 170mm length

Size: ML, L, XL, XXL

SRAM SX Eagle, 30T steel chainring, 49mm chainline, 175mm length

Bottom bracket Truvativ Powerspline, 73mm, threaded cartridge, 118mm spindle

Box SRAM PG-1210 Eagle, 11-50, 12 speed

Chain SRAM SX Eagle, 12 speed

Pedal VP-536 Nylon Platform

Max. crown size 1x: 34T, 2x: 36/22

Components

Saddle Bontrager Verse Short, stainless steel rails

*Seatpost Size: XXS, XS, S

TranzX JD-YSP18, 100mm travel, internal cable routing, 31.6mm, length 361mm

Size: M

TranzX JD-YSP18, 130mm travel, internal cable routing, 31.6mm, length 425mm

Size: ML, L, XL, XXL

TranzX JD-YSP18, 150mm travel, internal cable routing, 31.6mm, length 470mm

*Handlebar Size: XXS, XS

Bontrager Alloy, 31.8mm, 5mm rise, 690mm width

Size: S

Bontrager Alloy, 31.8mm, 15mm rise, 720mm width

Size: M, ML, L, XL, XXL

Bontrager Alloy, 31.8mm, 15mm rise, 750mm width

Knobs Bontrager XR Trail Comp, nylon block

*Handlebar stem Size: XXS, XS, S

Bontrager Comp, 31.8mm, 7 degrees, 35mm length

Size: M, ML, L

Bontrager Comp, 31.8mm, Blendr compatible, 7 degrees, 50mm length

Size: XL

Bontrager Comp, 31.8mm, Blendr compatible, 7 degrees, 60mm length

Size: XXL

Bontrager Comp, 31.8mm, Blendr compatible, 7 degrees, 70mm length

Steering series Semi-integrated, 1-1/8"

Brake Shimano MT200 hydraulic disc

*Brake rotor Size: XXS, XS, S, M, ML, L, XL, XXL

Shimano RT26, 6 bolts, 160mm

Size: M, ML, L, XL, XXL

Shimano RT26, 6 bolts,180mm

Brake set Shimano MT200 hydraulic disc

Disk size Max Brake Rotor Size - Frame: 180mm (XXS: 160mm), Fork: See fork manufacturer

Weight

Weight M - 15.03 kg / 33.14 lbs (with TLR sealant, tubeless)

Weight Limit This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136kg.
