Trek

TREK Rail+ 5 Gen 5 800Wh

€4,999.00
Tax included

Rail+ 5 is an alloy enduro e-bike that offers great value for big adventures. It features a full-power Bosch Performance CX drive system to tackle challenging trails and big climbs, while its generous battery offers plenty of range. 160mm of front and rear travel make Rail+ the ideal solution for rough and tumble terrain. Adjustable geometry lets you customize the bike to suit your riding needs.


Product available with different options

Chassis Alpha Platinum Aluminum, removable integrated battery (RIB 2.0), tapered head tube, guided internal routing, Motor Armor, angle-adjust headset, Mino Link adjustable geometry, adjustable leverage ratio, 34.9mm seat tube, ABP, UDH, Boost148, 12mm thru axle, 160mm travel

Fork RockShox Psylo Gold RC, DebonAir spring, Isolator RC damper, tapered steerer, 44mm offset, Boost 110, 15mm Maxle Stealth, 160mm travel

Suspension RockShox Deluxe Select+ RT, 205mm x 65mm

Max. compatible fork travel 180mm

Wheels

Front hub Bontrager sealed bearing, alloy axle, 6-bolt, Boost110, 15mm thru axle

Rear hub Bontrager alloy, sealed bearing, 6-bolt, Shimano MicroSpline freehub, Boost148, 12mm thru axle

Rear lock Bontrager Switch thru axle, removable lever

*Tire Size: S, M, L, XL

Bontrager Gunnison Elite XR, Tubeless Ready, rigid bead, 60tpi, 27.5x2.40"

Size: M, L, XL

Bontrager Gunnison Elite XR, Tubeless Ready, rigid bead, 60tpi, 29x2.40"

Pneumatic component Bontrager TLR Sealant, 6oz

Paranipple Bontrager TLR

Max. tire size Frame: 27.5x2.60", Fork: See manufacturer's data

Electronic system

Battrey Bosch PowerTube 800Wh, intelligent system

Charger Bosch standard 2A, 230V, intelligent system

Controller Bosch BRC3100 system controller, intelligent system

Motor Bosch Performance Line CX, max assistance 20mph/32km/h (max assistance 25km/h in EU and APAC)

Transmission

Command Shimano Deore M6100, 12 speed

Rear derailleur Shimano Deore M6100, long cage

Box Shimano Deore M6100, 10-51, 12 speed

Chain Shimano Deore M6100, 12 speed

Pedal VP-536 Nylon Platform

Max. crown size 1x: 36T

Components

Saddle Bontrager Verse P3, steel rails

*Seatpost Size: S

TranzX JD-YSI34, 100mm travel, internal cable routing, 34.9mm

Size: M, L, XL

TranzX JD-YSI34, 170mm travel, internal cable routing, 34.9mm

Handlebar Bontrager Alloy, 31.8mm, 15mm rise, 750mm width

Knobs Bontrager XR Trail Comp, nylon block

Handlebar stem Bontrager Comp, 31.8mm, Blendr compatible, 7 degrees, 50mm length

Brake Shimano 4-piston hydraulic disc, MT4100 levers, MT420 caliper

Brake rotor Shimano RT66, 6-bolt, 203mm

Disk size Max. brake rotor size - Frame: 220mm, Fork: See fork manufacturer

Accessories

Mudguards Trek 27.5” Custom Mudguard
