MAVIC Cosmic Sl 65 Disc 23mm

Hubs

Bearing technology: QRM automatic setting - sealed cartridge

Axle material: aluminum

Body material: aluminium

Freewheel: Shimano HG road / Sram XD road

Body design: INFINITY

Disc standard: Center Lock® only

Axle size: front 12x100 / rear 12x142

Rims

Tire: UST Tubeless Ready

Braking: disc

Drilling: traditional (front/rear 24 holes)

Material: 100% Unidirectional carbon fiber

Internal width: 23 mm

ETRTO size: 622x23TC

Height: 65 mm

Delivered with

User guide

UST valve not mounted on wheel

Front axle adapter: 12x100 convertible to 9x100

Rim tape mounted on wheel

Rear axle adapter: 12x142 convertible to 9x135

Multifonction adjustment wrench with the rear wheel

Spokes

Material: steel

Lacing: crossed 2 (front and rear)

Nipples: steel, ABS, black

Shape: straight, flat, antirot (front and rear)

Material : stainless steel

Intended use

ASTM category 2 : road and offroad with jumps less than 15cm

Maximum weight supported by the wheels: must not exceed 120 kg (bike weight included)

Maximum tyre size: width 64mm - pressure max. 3.25Bar/47PSI

Minimum tyre size: width 28mm - pressure max. 5.5Bar/80PSI

Compatibility

Freewheel body: SHIMANO HG light road

Freewheel body: convertible CAMPAGNOLO ED (kit V3440101 sold separately)

Freewheel body: convertible CAMPAGNOLO N3W (kit V4270101 sold separately)

Rear axle adapters: 12x142 convertible to 9x135 (kit V2510801 sold separately)

Freewheel body: convertible SHIMANO MS (kit V3990101 sold separately)

Front axle adapters: 12x100 convertible to 9x100 (kit V2680301 sold separately)

Freewheel body: convertible SRAM XD road (kit V2580101 sold separately)
