TREK Marlin 5

Frame Size: XXS , XS , S

Alpha Silver Aluminium, curved top tube, internal routing, chainstay disc brake mount, rack and kickstand mount, 135x5 mm QR

Size: M , ML , L , XL , XXL

Alpha Silver Aluminium, internal routing, chainstay disc-brake mount, rack and kickstand mount, 135x5 mm QR

Fork Size: XXS

SR Suntour XCM 30, coil spring, lockout, preload, 100 mm QR, 100 mm travel, 26" wheel

Size: XXS

SR Suntour XCT 30, coil spring, preload, hydraulic lockout, 42 mm offset for 26'' wheel, 100 mm QR, 100 mm travel

Size: XS

SR Suntour XCT 30, coil spring, preload, hydraulic lockout, 42 mm offset for 27.5" wheel, 100 mm QR, 80 mm travel

Size: S

SR Suntour XCT 30, coil spring, preload, hydraulic lockout, 42 mm offset for 27.5" wheel, 100 mm QR, 100 mm travel

Size: M , ML , L , XL , XXL

SR Suntour XCT 30, coil spring, preload, hydraulic lockout, 46 mm offset for 29" wheel, 100 mm QR, 100 mm travel

Max compatible fork travel 100mm (XS & S: 490mm axle-to-crown, M & up: 509mm axle-to-crown)

Wheels

Hub front Formula DC-20, alloy, 6-bolt, 5x100 mm QR

Hub rear Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR

Skewer rear 152x5 mm QR

Rim Bontrager Connection, double-wall, 32-hole, 20 mm width, Schrader valve

Tyre Size: XXS

Bontrager XR2 Comp, wire bead, 30 tpi, 26x2.20"

Size: XS , S

Bontrager XR2 Comp, wire bead, 30 tpi, 27.5x2.20"

Size: M , ML , L , XL , XXL

Bontrager XR2 Comp, wire bead, 30 tpi, 29x2.20"

Max tyre size Frame: 29x2.20" (XS & S: 27.5x2.4") Fork: See manufacturer

Drivetrain

Shifter Shimano Altus M315, 8-speed

Front derailleur Shimano Altus M315, 34.9 mm clamp, top swing, dual pull

Rear derailleur Shimano Altus M310

Crank Size: XXS

Prowheel TM-CY10, 36/22, 160 mm length

Size: XS , S , M

Shimano M315, 36/22, 170 mm length

Size: ML , L , XL , XXL

Shimano M315, 36/22, 175 mm length

Bottom bracket Sealed cartridge, 73mm

Cassette Shimano 8-speed, 12-32T

Chain KMC Z8.3, 8 speed

Max. chainring size 1x/2x: 34T, 3x: 42T
